Copper winding conductor for compact, efficient coils
Enamelled copper wire combines a high conductivity copper conductor with a controlled insulation coating. The thin film separates adjacent turns while allowing a greater amount of copper to fit within the available winding space.
K10 Cables offers selected diameters, builds and insulation systems. The appropriate construction depends on the thermal class, winding process, operating duty and applicable equipment specification.
Selected single coat and dual coat insulation systems
Multiple conductor diameters and overall builds
Options for different thermal class requirements
Suitable for manual and automated winding applications
Insulation systems
Available constructions may include polyester, polyester imide, polyamide imide and selected dual coat systems. Exact availability should be confirmed for the required conductor size and temperature class.
Information required for selection
- Bare conductor diameter and tolerance
- Overall diameter or insulation build
- Required thermal class
- Referenced IS, IEC or customer specification
- Spool size, packing and quantity
Reference standard availability varies by product. Confirm the current technical data before placing an order.
